OD1225-12MSS10A
Orion Fans
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFAN AXIAL 120X25MM 12VDC WIRE
- CategoryDC Brushless Fans (BLDC)
- Datasheet OD1225-12MSS10A Datasheet
-
ECAD Model
- Share
In Stock: 133
Can ship immediately
Pricing:
- 1$10.16262
- 520$10.16262
Quote It
Technical Details
- Series:OD1225
- Package:Bulk
- Part Status:Active
- Voltage - Rated:12VDC
- Size / Dimension:Square - 120mm L x 120mm H
- Width:25.00mm
- Air Flow:83.0 CFM (2.32m³/min)
- Static Pressure:0.120 in H2O (29.9 Pa)
- Bearing Type:Sealed Sleeve
- Fan Type:Tubeaxial
- Features:PWM Control, Speed Sensor (Tach)
- Noise:38.0dB
- Power (Watts):4 W
- RPM:2050 RPM
- Termination:4 Wire Leads
- Ingress Protection:-
- Operating Temperature:14 ~ 158°F (-10 ~ 70°C)
- Approval Agency:cURus, TUV
- Weight:-
