G4020H05B2-RSR-EM
Mechatronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFAN 40X20MM LCKD RTR IP57 05VDC
- CategoryDC Brushless Fans (BLDC)
- Datasheet G4020H05B2-RSR-EM Datasheet
-
ECAD Model
- Share
In Stock: 191
Can ship immediately
Pricing:
- 1$11.75933
- 300$11.75933
Quote It
Technical Details
- Series:G4020
- Package:Bulk
- Part Status:Active
- Voltage - Rated:5VDC
- Size / Dimension:Square - 40mm L x 40mm H
- Width:20.00mm
- Air Flow:11.0 CFM (0.308m³/min)
- Static Pressure:0.200 in H2O (49.8 Pa)
- Bearing Type:Ball
- Fan Type:Tubeaxial
- Features:Locked Rotor Sensor, Thermal Overload Protector (TOP)
- Noise:29.0dB(A)
- Power (Watts):-
- RPM:7000 RPM
- Termination:3 Wire Leads
- Ingress Protection:IP57 - Dust Protected, Waterproof
- Operating Temperature:-
- Approval Agency:CE, cUL, TUV, UL
- Weight:0.062 lb (28.12 g)
