9GV0412H3011

Technical Details

• Series:San Ace 40
• Package:Box
• Part Status:Active
• Voltage - Rated:12VDC
• Size / Dimension:Square - 40mm L x 40mm H
• Width:28.00mm
• Air Flow:18.7 CFM (0.524m³/min)
• Static Pressure:0.831 in H2O (207.0 Pa)
• Bearing Type:Ball
• Fan Type:Tubeaxial

• Features:Locked Rotor Protection, Speed Sensor (Tach)
• Noise:49.0dB(A)
• Power (Watts):3.72 W
• RPM:11600 RPM
• Termination:3 Wire Leads
• Ingress Protection:-
• Operating Temperature:-4 ~ 140°F (-20 ~ 60°C)
• Approval Agency:CSA, TUV, UL
• Weight:0.111 lb (50.35 g)
