GM1204PQV1-8A.GN
Sunon- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFAN BLOWER 40X28MM 12VDC
- CategoryDC Brushless Fans (BLDC)
- Datasheet GM1204PQV1-8A.GN Datasheet
-
ECAD Model
- Share
In Stock: 160
Can ship immediately
Pricing:
- 1$12.94033
- 30$12.94033
Quote It
Technical Details
- Series:MagLev® GM
- Package:Bulk
- Part Status:Obsolete
- Voltage - Rated:12VDC
- Size / Dimension:Square - 40mm L x 40mm H
- Width:28.00mm
- Air Flow:15.3 CFM (0.428m³/min)
- Static Pressure:0.520 in H2O (129.5 Pa)
- Bearing Type:Vapo-Bearing™
- Fan Type:Tubeaxial
- Features:Auto Restart, Locked Rotor Protection
- Noise:39.0dB(A)
- Power (Watts):2.8 W
- RPM:9200 RPM
- Termination:2 Wire Leads
- Ingress Protection:-
- Operating Temperature:14 ~ 158°F (-10 ~ 70°C)
- Approval Agency:CE, CUR, TUV, UL
- Weight:-
