PMD1208PKB3-A.(2).GN
Sunon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFAN AXIAL 80X20MM 12VDC
- CategoryDC Brushless Fans (BLDC)
- Datasheet PMD1208PKB3-A.(2).GN Datasheet
-
ECAD Model
- Share
In Stock: 112
Can ship immediately
Pricing:
- 1$13.39833
- 30$13.39833
Quote It
Technical Details
- Series:MagLev® PMD
- Package:Bulk
- Part Status:Active
- Voltage - Rated:12VDC
- Size / Dimension:Square - 80mm L x 80mm H
- Width:20.00mm
- Air Flow:45.0 CFM (1.26m³/min)
- Static Pressure:0.260 in H2O (64.8 Pa)
- Bearing Type:Ball
- Fan Type:Tubeaxial
- Features:Auto Restart
- Noise:44.0dB(A)
- Power (Watts):3.1 W
- RPM:3900 RPM
- Termination:2 Wire Leads
- Ingress Protection:-
- Operating Temperature:-
- Approval Agency:-
- Weight:-
