9GA0624H6D001
Sanyo Denki
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC AXIAL FAN 60X60X20MM LOCK
- CategoryDC Brushless Fans (BLDC)
-
ECAD Model
- Share
In Stock: 183
Can ship immediately
Pricing:
- 1$13.6522
Quote It
Technical Details
- Series:San Ace 60
- Package:Box
- Part Status:Active
- Voltage - Rated:24VDC
- Size / Dimension:Square - 60mm L x 60mm H
- Width:20.00mm
- Air Flow:18.4 CFM (0.515m³/min)
- Static Pressure:0.180 in H2O (44.8 Pa)
- Bearing Type:Ball
- Fan Type:Tubeaxial
- Features:Locked Rotor Sensor
- Noise:30.0dB(A)
- Power (Watts):960 mW
- RPM:4100 RPM
- Termination:3 Wire Leads
- Ingress Protection:-
- Operating Temperature:-4 ~ 158°F (-20 ~ 70°C)
- Approval Agency:CSA, TUV, UL
- Weight:0.156 lb (70.76 g)
