9G0912H1021
Sanyo Denki- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC AXIAL FAN 92X92X38MM
- CategoryDC Brushless Fans (BLDC)
-
ECAD Model
- Share
In Stock: 182
Can ship immediately
Pricing:
- 1$14.12524
Quote It
Technical Details
- Series:San Ace 92
- Package:Box
- Part Status:Active
- Voltage - Rated:12VDC
- Size / Dimension:Square - 92mm L x 92mm H
- Width:38.00mm
- Air Flow:90.0 CFM (2.52m³/min)
- Static Pressure:0.402 in H2O (100.1 Pa)
- Bearing Type:Ball
- Fan Type:Tubeaxial
- Features:Locked Rotor Protection
- Noise:43.0dB(A)
- Power (Watts):6.96 W
- RPM:4000 RPM
- Termination:2 Wire Leads
- Ingress Protection:-
- Operating Temperature:-4 ~ 140°F (-20 ~ 60°C)
- Approval Agency:CSA, TUV, UL
- Weight:0.397 lb (180.08 g)
