9G0812P1G04
Sanyo Denki
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFAN 80X38MM 12VDC TACH,PWM
- CategoryDC Brushless Fans (BLDC)
- Datasheet 9G0812P1G04 Datasheet
-
ECAD Model
- Share
In Stock: 139
Can ship immediately
Pricing:
- 1$14.34099
- 10$13.65876
- 25$12.80526
- 50$12.37842
- 100$11.35404
- 250$10.81333
Quote It
Technical Details
- Series:San Ace 80
- Package:Box
- Part Status:Active
- Voltage - Rated:12VDC
- Size / Dimension:Square - 80mm L x 80mm H
- Width:38.00mm
- Air Flow:90.0 CFM (2.52m³/min)
- Static Pressure:0.847 in H2O (211.0 Pa)
- Bearing Type:Ball
- Fan Type:Tubeaxial
- Features:Locked Rotor Protection, PWM Control, Speed Sensor (Tach)
- Noise:51.0dB(A)
- Power (Watts):13.2 W
- RPM:6300 RPM
- Termination:4 Wire Leads
- Ingress Protection:-
- Operating Temperature:-4 ~ 158°F (-20 ~ 70°C)
- Approval Agency:CSA, TUV, UL
- Weight:0.375 lb (170.1 g)
