9G1212P4H04
Sanyo Denki- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFAN 120X25MM 12VDC TACH,PWM
- CategoryDC Brushless Fans (BLDC)
- Datasheet 9G1212P4H04 Datasheet
-
ECAD Model
- Share
In Stock: 173
Can ship immediately
Pricing:
- 1$15.23733
- 60$13.9765
Quote It
Technical Details
- Series:San Ace 120
- Package:Box
- Part Status:Active
- Voltage - Rated:12VDC
- Size / Dimension:Square - 119mm L x 119mm H
- Width:25.00mm
- Air Flow:88.0 CFM (2.46m³/min)
- Static Pressure:0.257 in H2O (64.0 Pa)
- Bearing Type:Ball
- Fan Type:Tubeaxial
- Features:Locked Rotor Protection, PWM Control, Speed Sensor (Tach)
- Noise:40.0dB(A)
- Power (Watts):3.72 W
- RPM:2850 RPM
- Termination:4 Wire Leads
- Ingress Protection:-
- Operating Temperature:-4 ~ 158°F (-20 ~ 70°C)
- Approval Agency:CSA, TUV, UR
- Weight:0.529 lb (240.00 g)
