9G1212H4D011
Sanyo Denki- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC AXIAL FAN 120X120X25MM LOCK
- CategoryDC Brushless Fans (BLDC)
-
ECAD Model
- Share
In Stock: 164
Can ship immediately
Pricing:
- 1$15.48633
Quote It
Technical Details
- Series:San Ace 120
- Package:Box
- Part Status:Active
- Voltage - Rated:12VDC
- Size / Dimension:Square - 120mm L x 120mm H
- Width:25.00mm
- Air Flow:88.0 CFM (2.46m³/min)
- Static Pressure:0.257 in H2O (64.0 Pa)
- Bearing Type:Ball
- Fan Type:Tubeaxial
- Features:Locked Rotor Sensor
- Noise:40.0dB(A)
- Power (Watts):3.72 W
- RPM:2850 RPM
- Termination:3 Wire Leads
- Ingress Protection:-
- Operating Temperature:-4 ~ 158°F (-20 ~ 70°C)
- Approval Agency:CSA, TUV, UL
- Weight:0.529 lb (239.95 g)
