OD8038-48MB-VXC10A

Technical Details

• Series:OD8038 VA
• Package:Bulk
• Part Status:Active
• Voltage - Rated:48VDC
• Size / Dimension:Square - 80mm L x 80mm H
• Width:38.00mm
• Air Flow:89.0 CFM (2.49m³/min)
• Static Pressure:0.750 in H2O (186.8 Pa)
• Bearing Type:Ball
• Fan Type:Tubeaxial

• Features:Auto Restart, PWM Control, Speed Sensor (Tach)
• Noise:54.0dB
• Power (Watts):10 W
• RPM:5600 RPM
• Termination:4 Wire Leads
• Ingress Protection:-
• Operating Temperature:14 ~ 158°F (-10 ~ 70°C)
• Approval Agency:cURus, TUV
• Weight:-
