OD9238-24MBIP68
Orion Fans
- Lifecycle status Active
- RoHS RoHS Compliant
- Description24VDC 92X92X38MM IP68
- CategoryDC Brushless Fans (BLDC)
-
ECAD Model
- Share
In Stock: 107
Can ship immediately
Pricing:
- 1$16.02566
Quote It
Technical Details
- Series:OD9238
- Package:Box
- Part Status:Active
- Voltage - Rated:24VDC
- Size / Dimension:Square - 92mm L x 92mm H
- Width:38.00mm
- Air Flow:87.4 CFM (2.45m³/min)
- Static Pressure:0.550 in H2O (137.0 Pa)
- Bearing Type:Ball
- Fan Type:Tubeaxial
- Features:Auto Restart
- Noise:53.0dB
- Power (Watts):7.2 W
- RPM:4000 RPM
- Termination:2 Wire Leads
- Ingress Protection:IP68 - Dust Tight, Waterproof
- Operating Temperature:14 ~ 158°F (-10 ~ 70°C)
- Approval Agency:cURus, TUV
- Weight:0.441 lb (200.00 g)
