9GV0612P1L011
Sanyo Denki- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC AXIAL FAN 60X60X38MM PWM
- CategoryDC Brushless Fans (BLDC)
- Datasheet 9GV0612P1L011 Datasheet
-
ECAD Model
- Share
In Stock: 192
Can ship immediately
Pricing:
- 1$16.73144
Quote It
Technical Details
- Series:San Ace 60
- Package:Box
- Part Status:Active
- Voltage - Rated:12VDC
- Size / Dimension:Square - 60mm L x 60mm H
- Width:38.00mm
- Air Flow:52.6 CFM (1.47m³/min)
- Static Pressure:1.170 in H2O (291.4 Pa)
- Bearing Type:Ball
- Fan Type:Tubeaxial
- Features:PWM Control, Speed Sensor (Tach)
- Noise:52.0dB(A)
- Power (Watts):8.4 W
- RPM:10000 RPM
- Termination:4 Wire Leads
- Ingress Protection:-
- Operating Temperature:-4 ~ 158°F (-20 ~ 70°C)
- Approval Agency:CSA, TUV, UL
- Weight:0.287 lb (130.18 g)
