9G1248M1011
Sanyo Denki- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC AXIAL FAN 120X120X38MM TACH
- CategoryDC Brushless Fans (BLDC)
- Datasheet 9G1248M1011 Datasheet
-
ECAD Model
- Share
In Stock: 184
Can ship immediately
Pricing:
- 1$17.47571
Quote It
Technical Details
- Series:San Ace 120
- Package:Box
- Part Status:Active
- Voltage - Rated:48VDC
- Size / Dimension:Square - 120mm L x 120mm H
- Width:38.00mm
- Air Flow:74.0 CFM (2.07m³/min)
- Static Pressure:0.159 in H2O (39.6 Pa)
- Bearing Type:Ball
- Fan Type:Tubeaxial
- Features:Locked Rotor Protection, Speed Sensor (Tach)
- Noise:32.0dB(A)
- Power (Watts):3.36 W
- RPM:1950 RPM
- Termination:3 Wire Leads
- Ingress Protection:-
- Operating Temperature:-4 ~ 158°F (-20 ~ 70°C)
- Approval Agency:CSA, TUV, UL
- Weight:0.728 lb (330.22 g)
