9G1248E1D011
Sanyo Denki- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFAN 120X38MM 48VDC RBLS LOCK
- CategoryDC Brushless Fans (BLDC)
- Datasheet 9G1248E1D011 Datasheet
-
ECAD Model
- Share
In Stock: 156
Can ship immediately
Pricing:
- 1$18.04952
- 63$16.49968
Quote It
Technical Details
- Series:San Ace 120
- Package:Box
- Part Status:Active
- Voltage - Rated:48VDC
- Size / Dimension:Square - 119mm L x 119mm H
- Width:38.00mm
- Air Flow:118.0 CFM (3.30m³/min)
- Static Pressure:0.401 in H2O (100.0 Pa)
- Bearing Type:Ball
- Fan Type:Tubeaxial
- Features:Locked Rotor Sensor
- Noise:46.0dB(A)
- Power (Watts):8.16 W
- RPM:3100 RPM
- Termination:3 Wire Leads
- Ingress Protection:-
- Operating Temperature:-4 ~ 158°F (-20 ~ 70°C)
- Approval Agency:CSA, TUV, UL
- Weight:0.728 lb (330.22 g)
