9GA0812P1G611
Sanyo Denki- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC AXIAL FAN 80X80X38MM PWM
- CategoryDC Brushless Fans (BLDC)
- Datasheet 9GA0812P1G611 Datasheet
-
ECAD Model
- Share
In Stock: 189
Can ship immediately
Pricing:
- 1$19.81722
Quote It
Technical Details
- Series:San Ace 80
- Package:Box
- Part Status:Active
- Voltage - Rated:12VDC
- Size / Dimension:Square - 80mm L x 80mm H
- Width:38.00mm
- Air Flow:100.6 CFM (2.82m³/min)
- Static Pressure:1.930 in H2O (480.8 Pa)
- Bearing Type:Ball
- Fan Type:Tubeaxial
- Features:Locked Rotor Protection, PWM Control, Speed Sensor (Tach)
- Noise:60.0dB(A)
- Power (Watts):14.4 W
- RPM:10500 RPM
- Termination:4 Wire Leads
- Ingress Protection:-
- Operating Temperature:-4 ~ 158°F (-20 ~ 70°C)
- Approval Agency:CSA, TUV, UL
- Weight:0.353 lb (160.12 g)
