PMD2409PMB1-A (2).GN.IP55
Sunon- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFAN AXIAL 92X38MM 24VDC
- CategoryDC Brushless Fans (BLDC)
- Datasheet PMD2409PMB1-A (2).GN.IP55 Datasheet
-
ECAD Model
- Share
In Stock: 147
Can ship immediately
Pricing:
- 1$20.53533
- 30$20.53533
Quote It
Technical Details
- Series:PMD
- Package:Bulk
- Part Status:Active
- Voltage - Rated:24VDC
- Size / Dimension:Square - 92mm L x 92mm H
- Width:38.00mm
- Air Flow:120.2 CFM (3.37m³/min)
- Static Pressure:0.710 in H2O (176.9 Pa)
- Bearing Type:Ball
- Fan Type:Tubeaxial
- Features:Auto Restart, Locked Rotor Protection
- Noise:57.6dB(A)
- Power (Watts):12.2 W
- RPM:4900 RPM
- Termination:2 Wire Leads
- Ingress Protection:IP55 - Dust Protected, Water Resistant
- Operating Temperature:14 ~ 158°F (-10 ~ 70°C)
- Approval Agency:CE, CUR, TUV, UL
- Weight:-
