PMD1212PTB1-A (2).GN.IP55
Sunon- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFAN AXIAL 120X25MM 12VDC
- CategoryDC Brushless Fans (BLDC)
- Datasheet PMD1212PTB1-A (2).GN.IP55 Datasheet
-
ECAD Model
- Share
In Stock: 116
Can ship immediately
Pricing:
- 1$21.66
- 30$21.66
Quote It
Technical Details
- Series:PMD
- Package:Bulk
- Part Status:Active
- Voltage - Rated:12VDC
- Size / Dimension:Square - 120mm L x 120mm H
- Width:25.00mm
- Air Flow:150.0 CFM (4.20m³/min)
- Static Pressure:0.620 in H2O (154.4 Pa)
- Bearing Type:Ball
- Fan Type:Tubeaxial
- Features:Auto Restart, Locked Rotor Protection
- Noise:54.0dB(A)
- Power (Watts):12 W
- RPM:4500 RPM
- Termination:2 Wire Leads
- Ingress Protection:IP55 - Dust Protected, Water Resistant
- Operating Temperature:14 ~ 158°F (-10 ~ 70°C)
- Approval Agency:CE, CUR, TUV, UL
- Weight:-
