9GA0712P1G0011
Sanyo Denki
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFAN 70X38MM 12VDC RBLS TACH,PWM
- CategoryDC Brushless Fans (BLDC)
- Datasheet 9GA0712P1G0011 Datasheet
-
ECAD Model
- Share
In Stock: 111
Can ship immediately
Pricing:
- 1$23.91083
- 60$21.85783
Quote It
Technical Details
- Series:San Ace 70
- Package:Box
- Part Status:Active
- Voltage - Rated:12VDC
- Size / Dimension:Square - 70mm L x 70mm H
- Width:38.00mm
- Air Flow:93.6 CFM (2.62m³/min)
- Static Pressure:3.453 in H2O (860.1 Pa)
- Bearing Type:Ball
- Fan Type:Tubeaxial
- Features:PWM Control, Speed Sensor (Tach)
- Noise:65.0dB(A)
- Power (Watts):31.2 W
- RPM:16500 RPM
- Termination:4 Wire Leads
- Ingress Protection:-
- Operating Temperature:-4 ~ 158°F (-20 ~ 70°C)
- Approval Agency:CSA, TUV, UL
- Weight:0.375 lb (170.1 g)
