9LG0924S4D001
Sanyo Denki
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC AXIAL FAN 92X92X25MM LOCK
- CategoryDC Brushless Fans (BLDC)
-
ECAD Model
- Share
In Stock: 179
Can ship immediately
Pricing:
- 1$45.83679
Quote It
Technical Details
- Series:San Ace 92L
- Package:Box
- Part Status:Active
- Voltage - Rated:24VDC
- Size / Dimension:Square - 92mm L x 92mm H
- Width:25.20mm
- Air Flow:59.7 CFM (1.67m³/min)
- Static Pressure:0.250 in H2O (62.3 Pa)
- Bearing Type:Ball
- Fan Type:Tubeaxial
- Features:Locked Rotor Sensor
- Noise:37.0dB(A)
- Power (Watts):2.64 W
- RPM:3850 RPM
- Termination:3 Wire Leads
- Ingress Protection:-
- Operating Temperature:-4 ~ 158°F (-20 ~ 70°C)
- Approval Agency:CSA, TUV, UL
- Weight:0.331 lb (150.14 g)
