AFB1548HH-AF00
Delta Electronics / Fans- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFAN 172X150X25.4MM
- CategoryDC Brushless Fans (BLDC)
-
ECAD Model
- Share
In Stock: 116
Can ship immediately
Pricing:
- 1$48.59403
Quote It
Technical Details
- Series:AFB
- Package:Bulk
- Part Status:Active
- Voltage - Rated:48VDC
- Size / Dimension:Rectangular/Rounded - 172mm L x 150mm H
- Width:25.40mm
- Air Flow:218.4 CFM (6.12m³/min)
- Static Pressure:0.452 in H2O (112.6 Pa)
- Bearing Type:Ball
- Fan Type:Tubeaxial
- Features:Locked Rotor Protection, Speed Sensor (Tach)
- Noise:54.5dB(A)
- Power (Watts):14.88 W
- RPM:3200 RPM
- Termination:3 Wire Leads
- Ingress Protection:-
- Operating Temperature:14 ~ 158°F (-10 ~ 70°C)
- Approval Agency:-
- Weight:0.948 lb (430.01 g)
