19039355A
Comair Rotron
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFAN AXIAL 172X50.8MM PQ12B4QNN
- CategoryDC Brushless Fans (BLDC)
- Datasheet 19039355A Datasheet
-
ECAD Model
- Share
In Stock: 182
Can ship immediately
Pricing:
- 1$56.596
- 100$56.596
Quote It
Technical Details
- Series:Patriot
- Package:Box
- Part Status:Active
- Voltage - Rated:12VDC
- Size / Dimension:Round - 172mm Dia
- Width:50.80mm
- Air Flow:235.0 CFM (6.58m³/min)
- Static Pressure:0.769 in H2O (191.5 Pa)
- Bearing Type:Ball
- Fan Type:Tubeaxial
- Features:Auto Restart, Fan Performance Sensor (FPS), Locked Rotor Protection
- Noise:51.2dB(A)
- Power (Watts):26.3 W
- RPM:3500 RPM
- Termination:2 Terminals and 3 Wire Leads
- Ingress Protection:-
- Operating Temperature:14 ~ 158°F (-10 ~ 70°C)
- Approval Agency:CE, UL
- Weight:1.8 lbs (816.5 g)
