109E1724M501
Sanyo Denki- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionDC AXIAL FAN 172X51MM TACH
- CategoryDC Brushless Fans (BLDC)
-
ECAD Model
- Share
In Stock: 116
Can ship immediately
Pricing:
- 1$57.46375
Quote It
Technical Details
- Series:San Ace 172
- Package:Box
- Part Status:Active
- Voltage - Rated:24VDC
- Size / Dimension:Round - 172mm Dia
- Width:51.00mm
- Air Flow:148.0 CFM (4.14m³/min)
- Static Pressure:0.271 in H2O (67.6 Pa)
- Bearing Type:Ball
- Fan Type:Tubeaxial
- Features:Locked Rotor Protection, Speed Sensor (Tach)
- Noise:36.0dB(A)
- Power (Watts):4.8 W
- RPM:2000 RPM
- Termination:3 Wire Leads
- Ingress Protection:-
- Operating Temperature:-4 ~ 158°F (-20 ~ 70°C)
- Approval Agency:CSA, TUV, UL
- Weight:1.7 lbs (780.0 g)
