GM0502PFV2-8.GN

Technical Details

• Series:MagLev® GM
• Package:Bulk
• Part Status:Obsolete
• Voltage - Rated:5VDC
• Size / Dimension:Square - 25mm L x 25mm H
• Width:10.00mm
• Air Flow:3.0 CFM (0.084m³/min)
• Static Pressure:0.180 in H2O (44.8 Pa)
• Bearing Type:Vapo-Bearing™
• Fan Type:Tubeaxial

• Features:-
• Noise:16.0dB(A)
• Power (Watts):400 mW
• RPM:10000 RPM
• Termination:2 Wire Leads
• Ingress Protection:-
• Operating Temperature:14 ~ 158°F (-10 ~ 70°C)
• Approval Agency:CE, CUR, TUV, UL
• Weight:0.017 lb (7.71 g)
