PMB1275PNB1-AY.(2).GN

Technical Details

• Series:PMB
• Package:Bulk
• Part Status:Obsolete
• Voltage - Rated:12VDC
• Size / Dimension:Square/Rounded - 75.7mm L x 75.7mm H
• Width:30.00mm
• Air Flow:13.6 CFM (0.381m³/min)
• Static Pressure:0.600 in H2O (149.5 Pa)
• Bearing Type:Ball
• Fan Type:Blower

• Features:-
• Noise:43.5dB(A)
• Power (Watts):3.6 W
• RPM:3400 RPM
• Termination:2 Wire Leads
• Ingress Protection:-
• Operating Temperature:14 ~ 158°F (-10 ~ 70°C)
• Approval Agency:CE, CUR, TUV, UL
• Weight:0.191 lb (86.64 g)
