PMD4812PTB1-A.(2).GN
Sunon
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFAN AXIAL 120X25MM 48VDC WIRE
- CategoryDC Brushless Fans (BLDC)
- Datasheet PMD4812PTB1-A.(2).GN Datasheet
-
ECAD Model
- Share
In Stock: 145
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:PMD
- Package:Box
- Part Status:Obsolete
- Voltage - Rated:48VDC
- Size / Dimension:Square - 120mm L x 120mm H
- Width:25.00mm
- Air Flow:150.0 CFM (4.20m³/min)
- Static Pressure:0.620 in H2O (154.4 Pa)
- Bearing Type:Ball
- Fan Type:Tubeaxial
- Features:-
- Noise:54.0dB(A)
- Power (Watts):12.5 W
- RPM:4500 RPM
- Termination:2 Wire Leads
- Ingress Protection:-
- Operating Temperature:14 ~ 158°F (-10 ~ 70°C)
- Approval Agency:CE, CUR, TUV, UL
- Weight:0.485 lb (219.99 g)
