3108NL-05W-B39-P00
NMB Technologies Corp.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionFAN AXIAL 80X20MM 24VDC WIRE
- CategoryDC Brushless Fans (BLDC)
- Datasheet 3108NL-05W-B39-P00 Datasheet
-
ECAD Model
- Share
In Stock: 158
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:3108NL
- Package:Box
- Part Status:Obsolete
- Voltage - Rated:24VDC
- Size / Dimension:Square - 80mm L x 80mm H
- Width:20.00mm
- Air Flow:34.6 CFM (0.969m³/min)
- Static Pressure:0.134 in H2O (33.5 Pa)
- Bearing Type:Ball
- Fan Type:Tubeaxial
- Features:Locked Rotor Sensor
- Noise:32.5dB
- Power (Watts):1.68 W
- RPM:2950 RPM
- Termination:3 Wire Leads
- Ingress Protection:-
- Operating Temperature:14 ~ 158°F (-10 ~ 70°C)
- Approval Agency:CE, CSA, UL, VDE
- Weight:0.187 lb (84.82 g)
