UB3F3-700

Technical Details

• Series:MagLev® UB, Mighty Mini
• Package:Tray
• Part Status:Obsolete
• Voltage - Rated:3VDC
• Size / Dimension:Square - 15mm L x 15mm H
• Width:3.00mm
• Air Flow:0.160 CFM (0.004m³/min)
• Static Pressure:0.116 in H2O (28.8 Pa)
• Bearing Type:Vapo-Bearing™
• Fan Type:Blower

• Features:Auto Restart
• Noise:30.0dB(A)
• Power (Watts):100 mW
• RPM:14000 RPM
• Termination:2 Wire Leads
• Ingress Protection:IP55 - Dust Protected, Water Resistant
• Operating Temperature:14 ~ 158°F (-10 ~ 70°C)
• Approval Agency:CE
• Weight:0.003 lb (1.36 g)
