BC559
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTRANS PNP 30V 100MA TO92-3
- CategoryTransistors - Bipolar (BJT) - Single
- Datasheet BC559 Datasheet
-
ECAD Model
- Share
In Stock: 37,640
Can ship immediately
Pricing:
- 1$0.04
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Obsolete
- Transistor Type:PNP
- Current - Collector (Ic) (Max):100 mA
- Voltage - Collector Emitter Breakdown (Max):30 V
- Vce Saturation (Max) @ Ib, Ic:650mV @ 5mA, 100mA
- Current - Collector Cutoff (Max):15nA (ICBO)
- DC Current Gain (hFE) (Min) @ Ic, Vce:110 @ 2mA, 5V
- Power - Max:500 mW
- Frequency - Transition:150MHz
- Operating Temperature:150°C (TJ)
- Mounting Type:Through Hole
- Package / Case:TO-226-3, TO-92-3 (TO-226AA)
- Supplier Device Package:TO-92-3
