2SA1705S-AN
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTRANS PNP 50V 1A 3NMP
- CategoryTransistors - Bipolar (BJT) - Single
- Datasheet 2SA1705S-AN Datasheet
-
ECAD Model
- Share
In Stock: 7,680
Can ship immediately
Pricing:
- 1$0.11
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Obsolete
- Transistor Type:PNP
- Current - Collector (Ic) (Max):1 A
- Voltage - Collector Emitter Breakdown (Max):50 V
- Vce Saturation (Max) @ Ib, Ic:500mV @ 50mA, 500mA
- Current - Collector Cutoff (Max):100nA (ICBO)
- DC Current Gain (hFE) (Min) @ Ic, Vce:100 @ 100mA, 2V
- Power - Max:900 mW
- Frequency - Transition:150MHz
- Operating Temperature:150°C (TJ)
- Mounting Type:Through Hole
- Package / Case:SC-71
- Supplier Device Package:3-NMP
