TN6705A
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTRANS NPN 45V 1.5A TO226-3
- CategoryTransistors - Bipolar (BJT) - Single
- Datasheet TN6705A Datasheet
-
ECAD Model
- Share
In Stock: 8,840
Can ship immediately
Pricing:
- 1$0.12
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Obsolete
- Transistor Type:NPN
- Current - Collector (Ic) (Max):1.5 A
- Voltage - Collector Emitter Breakdown (Max):45 V
- Vce Saturation (Max) @ Ib, Ic:1V @ 100mA, 1A
- Current - Collector Cutoff (Max):100nA (ICBO)
- DC Current Gain (hFE) (Min) @ Ic, Vce:40 @ 250mA, 2V
- Power - Max:1 W
- Frequency - Transition:-
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Package / Case:TO-226-3, TO-92-3 (TO-226AA)
- Supplier Device Package:TO-226-3
