PZTA42
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionNPN 300V HI BIPOLR SOT223 SNGL
- CategoryTransistors - Bipolar (BJT) - Single
- Datasheet PZTA42 Datasheet
-
ECAD Model
- Share
In Stock: 39,994
Can ship immediately
Pricing:
- 1$0.14
- 4,000$0.13947
- 8,000$0.13101
- 12,000$0.12256
- 28,000$0.1127
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Transistor Type:NPN
- Current - Collector (Ic) (Max):500 mA
- Voltage - Collector Emitter Breakdown (Max):300 V
- Vce Saturation (Max) @ Ib, Ic:500mV @ 2mA, 20mA
- Current - Collector Cutoff (Max):100nA (ICBO)
- DC Current Gain (hFE) (Min) @ Ic, Vce:40 @ 30mA, 10V
- Power - Max:1 W
- Frequency - Transition:50MHz
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:TO-261-4, TO-261AA
- Supplier Device Package:SOT-223 (TO-261)
