NZT6717
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- Description1.2A, 80V, NPN
- CategoryTransistors - Bipolar (BJT) - Single
- Datasheet NZT6717 Datasheet
-
ECAD Model
- Share
In Stock: 16,238
Can ship immediately
Pricing:
- 1$0.14
- 4,000$0.13825
- 8,000$0.12988
- 12,000$0.1215
- 28,000$0.11172
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Transistor Type:NPN
- Current - Collector (Ic) (Max):1.2 A
- Voltage - Collector Emitter Breakdown (Max):80 V
- Vce Saturation (Max) @ Ib, Ic:350mV @ 10mA, 250mA
- Current - Collector Cutoff (Max):100nA (ICBO)
- DC Current Gain (hFE) (Min) @ Ic, Vce:50 @ 250mA, 1V
- Power - Max:1 W
- Frequency - Transition:-
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:TO-261-4, TO-261AA
- Supplier Device Package:SOT-223-4
