TIP31B
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionPOWER BIPOLAR TRANSISTOR, NPN
- CategoryTransistors - Bipolar (BJT) - Single
- Datasheet TIP31B Datasheet
-
ECAD Model
- Share
In Stock: 7,727
Can ship immediately
Pricing:
- 1$0.15
- 1,600$0.15
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Transistor Type:NPN
- Current - Collector (Ic) (Max):3 A
- Voltage - Collector Emitter Breakdown (Max):80 V
- Vce Saturation (Max) @ Ib, Ic:1.2V @ 375mA, 3A
- Current - Collector Cutoff (Max):300µA
- DC Current Gain (hFE) (Min) @ Ic, Vce:10 @ 3A, 4V
- Power - Max:2 W
- Frequency - Transition:3MHz
- Operating Temperature:150°C (TJ)
- Mounting Type:Through Hole
- Package / Case:TO-220-3
- Supplier Device Package:TO-220-3
