TIP126
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionPOWER BIPOLAR TRANSISTOR, PNP
- CategoryTransistors - Bipolar (BJT) - Single
- Datasheet TIP126 Datasheet
-
ECAD Model
- Share
In Stock: 7,459
Can ship immediately
Pricing:
- 1$0.2
- 10$0.17118
- 100$0.12788
- 500$0.10048
- 1,000$0.07765
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Transistor Type:PNP - Darlington
- Current - Collector (Ic) (Max):5 A
- Voltage - Collector Emitter Breakdown (Max):80 V
- Vce Saturation (Max) @ Ib, Ic:4V @ 20mA, 5A
- Current - Collector Cutoff (Max):500µA
- DC Current Gain (hFE) (Min) @ Ic, Vce:1000 @ 3A, 3V
- Power - Max:65 W
- Frequency - Transition:4MHz
- Operating Temperature:-65°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Package / Case:TO-220-3
- Supplier Device Package:TO-220
