BDX54CTU
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionPOWER BIPOLAR TRANSISTOR
- CategoryTransistors - Bipolar (BJT) - Single
- Datasheet BDX54CTU Datasheet
-
ECAD Model
- Share
In Stock: 5,111
Can ship immediately
Pricing:
- 1$0.34
- 10$0.29954
- 100$0.23133
- 500$0.18446
- 1,000$0.14908
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Transistor Type:PNP - Darlington
- Current - Collector (Ic) (Max):8 A
- Voltage - Collector Emitter Breakdown (Max):100 V
- Vce Saturation (Max) @ Ib, Ic:2V @ 12mA, 3A
- Current - Collector Cutoff (Max):500µA
- DC Current Gain (hFE) (Min) @ Ic, Vce:750 @ 3A, 3V
- Power - Max:60 W
- Frequency - Transition:-
- Operating Temperature:150°C (TJ)
- Mounting Type:Through Hole
- Package / Case:TO-220-3
- Supplier Device Package:TO-220-3
