2SA1615-Z-E1-AZ
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- Description10A, 20V, PNP
- CategoryTransistors - Bipolar (BJT) - Single
-
ECAD Model
- Share
In Stock: 3,676
Can ship immediately
Pricing:
- 1$0.61
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Transistor Type:PNP
- Current - Collector (Ic) (Max):10 A
- Voltage - Collector Emitter Breakdown (Max):20 V
- Vce Saturation (Max) @ Ib, Ic:250mV @ 50mA, 4A
- Current - Collector Cutoff (Max):1µA (ICBO)
- DC Current Gain (hFE) (Min) @ Ic, Vce:200 @ 500mA, 2V
- Power - Max:1 W
- Frequency - Transition:180MHz
- Operating Temperature:150°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:TO-252-3, DPak (2 Leads + Tab), SC-63
- Supplier Device Package:TO-252 (MP-3Z)
