KSD526Y
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTRANS NPN 80V 4A TO220-3
- CategoryTransistors - Bipolar (BJT) - Single
- Datasheet KSD526Y Datasheet
-
ECAD Model
- Share
In Stock: 117,112,155
Can ship immediately
Pricing:
- 1$0.79
- 1,200$0.79
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Transistor Type:NPN
- Current - Collector (Ic) (Max):4 A
- Voltage - Collector Emitter Breakdown (Max):80 V
- Vce Saturation (Max) @ Ib, Ic:1.5V @ 300mA, 3A
- Current - Collector Cutoff (Max):30µA (ICBO)
- DC Current Gain (hFE) (Min) @ Ic, Vce:120 @ 500mA, 5V
- Power - Max:30 W
- Frequency - Transition:8MHz
- Operating Temperature:150°C (TJ)
- Mounting Type:Through Hole
- Package / Case:TO-220-3
- Supplier Device Package:TO-220-3
