MMBT2222ALT1

Technical Details

• Series:*
• Package:Bulk
• Part Status:Active
• Transistor Type:NPN
• Current - Collector (Ic) (Max):600 mA
• Voltage - Collector Emitter Breakdown (Max):40 V
• Vce Saturation (Max) @ Ib, Ic:1V @ 50mA, 500mA
• Current - Collector Cutoff (Max):10nA (ICBO)

• DC Current Gain (hFE) (Min) @ Ic, Vce:100 @ 150mA, 10V
• Power - Max:225 mW
• Frequency - Transition:300MHz
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Surface Mount
• Package / Case:TO-236-3, SC-59, SOT-23-3
• Supplier Device Package:SOT-23-3 (TO-236)
