2N3904TAR
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSMALL SIGNAL BIPOLAR TRANSISTOR,
- CategoryTransistors - Bipolar (BJT) - Single
- Datasheet 2N3904TAR Datasheet
-
ECAD Model
- Share
In Stock: 2,146
Can ship immediately
Pricing:
- 1$0.03
- 2,000$0.03
- 6,000$0.02622
- 10,000$0.02245
- 50,000$0.01994
- 100,000$0.01784
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Transistor Type:NPN
- Current - Collector (Ic) (Max):200 mA
- Voltage - Collector Emitter Breakdown (Max):40 V
- Vce Saturation (Max) @ Ib, Ic:300mV @ 5mA, 50mA
- Current - Collector Cutoff (Max):50nA
- DC Current Gain (hFE) (Min) @ Ic, Vce:100 @ 10mA, 1V
- Power - Max:625 mW
- Frequency - Transition:300MHz
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Package / Case:TO-226-3, TO-92-3 (TO-226AA) Formed Leads
- Supplier Device Package:TO-92-3
