PZT3904
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSMALL SIGNAL BIPOLAR TRANSISTOR,
- CategoryTransistors - Bipolar (BJT) - Single
- Datasheet PZT3904 Datasheet
-
ECAD Model
- Share
In Stock: 106,827
Can ship immediately
Pricing:
- 1$0.11
- 4,000$0.11
- 8,000$0.10333
- 12,000$0.09667
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Obsolete
- Transistor Type:NPN
- Current - Collector (Ic) (Max):200 mA
- Voltage - Collector Emitter Breakdown (Max):40 V
- Vce Saturation (Max) @ Ib, Ic:300mV @ 5mA, 50mA
- Current - Collector Cutoff (Max):-
- DC Current Gain (hFE) (Min) @ Ic, Vce:100 @ 10mA, 1V
- Power - Max:1 W
- Frequency - Transition:300MHz
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:TO-261-4, TO-261AA
- Supplier Device Package:SOT-223-4
