NJL0302DG
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionPOWER BIPOLAR TRANSISTOR, 15A, 2
- CategoryTransistors - Bipolar (BJT) - Single
- Datasheet NJL0302DG Datasheet
-
ECAD Model
- Share
In Stock: 2,468
Can ship immediately
Pricing:
- 1$2.3
- 25$1.95506
- 100$1.69441
- 500$1.44242
- 1,000$1.21648
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Transistor Type:PNP
- Current - Collector (Ic) (Max):15 A
- Voltage - Collector Emitter Breakdown (Max):260 V
- Vce Saturation (Max) @ Ib, Ic:1V @ 500mA, 5A
- Current - Collector Cutoff (Max):10µA (ICBO)
- DC Current Gain (hFE) (Min) @ Ic, Vce:75 @ 3A, 5V
- Power - Max:180 W
- Frequency - Transition:30MHz
- Operating Temperature:-65°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Package / Case:TO-264-5
- Supplier Device Package:TO-264
