MJ10015
NTE Electronics, Inc.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionT-NPN SI- PO HIV DARL
- CategoryTransistors - Bipolar (BJT) - Single
-
ECAD Model
- Share
In Stock: 217
Can ship immediately
Pricing:
- 1$12
Quote It
Technical Details
- Series:SWITCHMODE™
- Package:Bag
- Part Status:Active
- Transistor Type:NPN - Darlington
- Current - Collector (Ic) (Max):50 A
- Voltage - Collector Emitter Breakdown (Max):400 V
- Vce Saturation (Max) @ Ib, Ic:5V @ 10A, 50A
- Current - Collector Cutoff (Max):250µA
- DC Current Gain (hFE) (Min) @ Ic, Vce:25 @ 20A, 5V
- Power - Max:250 W
- Frequency - Transition:-
- Operating Temperature:-65°C ~ 200°C (TJ)
- Mounting Type:Through Hole
- Package / Case:TO-204AA, TO-3
- Supplier Device Package:TO-3
