MMBT2222AWT1
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTRANS NPN 40V 600MA SC70-3
- CategoryTransistors - Bipolar (BJT) - Single
- Datasheet MMBT2222AWT1 Datasheet
-
ECAD Model
- Share
In Stock: 165
Can ship immediately
Pricing:
- 1$0.02
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Obsolete
- Transistor Type:NPN
- Current - Collector (Ic) (Max):600 mA
- Voltage - Collector Emitter Breakdown (Max):40 V
- Vce Saturation (Max) @ Ib, Ic:300mV @ 15mA, 150mA
- Current - Collector Cutoff (Max):-
- DC Current Gain (hFE) (Min) @ Ic, Vce:100 @ 150mA, 10V
- Power - Max:150 mW
- Frequency - Transition:300MHz
- Operating Temperature:-
- Mounting Type:Surface Mount
- Package / Case:SC-70, SOT-323
- Supplier Device Package:SC-70-3 (SOT323)
