2N5172
NTE Electronics, Inc.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTRANS NPN 25V 500MA TO92-3
- CategoryTransistors - Bipolar (BJT) - Single
- Datasheet 2N5172 Datasheet
-
ECAD Model
- Share
In Stock: 156
Can ship immediately
Pricing:
- 1$0.76
- 10$0.64178
- 25$0.56409
- 100$0.48598
- 250$0.42357
- 500$0.36115
- 1,000$0.28313
- 2,500$0.25972
- 5,000$0.24411
Quote It
Technical Details
- Series:-
- Package:Bag
- Part Status:Active
- Transistor Type:NPN
- Current - Collector (Ic) (Max):500 mA
- Voltage - Collector Emitter Breakdown (Max):25 V
- Vce Saturation (Max) @ Ib, Ic:250mV @ 1mA, 10mA
- Current - Collector Cutoff (Max):100nA (ICBO)
- DC Current Gain (hFE) (Min) @ Ic, Vce:100 @ 10mA, 10V
- Power - Max:625 mW
- Frequency - Transition:-
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Package / Case:TO-226-3, TO-92-3 (TO-226AA)
- Supplier Device Package:TO-92-3
