MJE13005
NTE Electronics, Inc.
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTRANS NPN 400V 4A TO220AB
- CategoryTransistors - Bipolar (BJT) - Single
- Datasheet MJE13005 Datasheet
-
ECAD Model
- Share
In Stock: 188
Can ship immediately
Pricing:
- 1$1.12
- 10$0.99987
- 25$0.89982
- 100$0.81983
- 250$0.73984
- 500$0.66386
- 1,000$0.55988
- 2,500$0.53322
Quote It
Technical Details
- Series:SWITCHMODE™
- Package:Bag
- Part Status:Active
- Transistor Type:NPN
- Current - Collector (Ic) (Max):4 A
- Voltage - Collector Emitter Breakdown (Max):400 V
- Vce Saturation (Max) @ Ib, Ic:1V @ 1A, 4A
- Current - Collector Cutoff (Max):-
- DC Current Gain (hFE) (Min) @ Ic, Vce:8 @ 2A, 5V
- Power - Max:2 W
- Frequency - Transition:4MHz
- Operating Temperature:-65°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Package / Case:TO-220-3
- Supplier Device Package:TO-220AB
