MMBT2222AT
Rochester Electronics
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionSMALL SIGNAL BIPOLAR TRANSISTOR,
- CategoryTransistors - Bipolar (BJT) - Single
- Datasheet MMBT2222AT Datasheet
-
ECAD Model
- Share
In Stock: 179
Can ship immediately
Pricing:
- 1$0.04
- 3,000$0.04
- 6,000$0.03478
- 15,000$0.02957
- 30,000$0.02783
- 75,000$0.02609
- 150,000$0.02319
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Active
- Transistor Type:NPN
- Current - Collector (Ic) (Max):600 mA
- Voltage - Collector Emitter Breakdown (Max):40 V
- Vce Saturation (Max) @ Ib, Ic:1V @ 50mA, 500mA
- Current - Collector Cutoff (Max):-
- DC Current Gain (hFE) (Min) @ Ic, Vce:100 @ 150mA, 1V
- Power - Max:250 mW
- Frequency - Transition:300MHz
- Operating Temperature:150°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:SC-89, SOT-490
- Supplier Device Package:SOT-523F
