BSP 52 E6327
IR (Infineon Technologies)
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTRANS NPN DARL 80V 1A SOT-223
- CategoryTransistors - Bipolar (BJT) - Single
- Datasheet BSP 52 E6327 Datasheet
-
ECAD Model
- Share
In Stock: 138
Can ship immediately
Pricing:
- 1$0.49
Quote It
Technical Details
- Series:-
- Package:Tape & Reel (TR)Cut Tape (CT)
- Part Status:Obsolete
- Transistor Type:NPN - Darlington
- Current - Collector (Ic) (Max):1 A
- Voltage - Collector Emitter Breakdown (Max):80 V
- Vce Saturation (Max) @ Ib, Ic:1.8V @ 1mA, 1A
- Current - Collector Cutoff (Max):10µA
- DC Current Gain (hFE) (Min) @ Ic, Vce:2000 @ 500mA, 10V
- Power - Max:1.5 W
- Frequency - Transition:200MHz
- Operating Temperature:150°C (TJ)
- Mounting Type:Surface Mount
- Package / Case:TO-261-4, TO-261AA
- Supplier Device Package:PG-SOT223-4
