P2N2222A
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTRANS NPN 40V 0.6A TO92
- CategoryTransistors - Bipolar (BJT) - Single
- Datasheet P2N2222A Datasheet
-
ECAD Model
- Share
In Stock: 171
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Bulk
- Part Status:Obsolete
- Transistor Type:NPN
- Current - Collector (Ic) (Max):600 mA
- Voltage - Collector Emitter Breakdown (Max):40 V
- Vce Saturation (Max) @ Ib, Ic:1V @ 50mA, 500mA
- Current - Collector Cutoff (Max):10nA
- DC Current Gain (hFE) (Min) @ Ic, Vce:100 @ 150mA, 10V
- Power - Max:625 mW
- Frequency - Transition:300MHz
- Operating Temperature:-55°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Package / Case:TO-226-3, TO-92-3 (TO-226AA)
- Supplier Device Package:TO-92-3
