MJH11022
ON Semiconductor
- Lifecycle status Active
- RoHS RoHS Compliant
- DescriptionTRANS NPN DARL 250V 15A TO218
- CategoryTransistors - Bipolar (BJT) - Single
- Datasheet MJH11022 Datasheet
-
ECAD Model
- Share
In Stock: 168
Can ship immediately
Pricing:
Call for price or sumbit a RFQ
Quote It
Technical Details
- Series:-
- Package:Tube
- Part Status:Obsolete
- Transistor Type:NPN - Darlington
- Current - Collector (Ic) (Max):15 A
- Voltage - Collector Emitter Breakdown (Max):250 V
- Vce Saturation (Max) @ Ib, Ic:4V @ 150mA, 15A
- Current - Collector Cutoff (Max):1mA
- DC Current Gain (hFE) (Min) @ Ic, Vce:400 @ 10A, 5V
- Power - Max:150 W
- Frequency - Transition:3MHz
- Operating Temperature:-65°C ~ 150°C (TJ)
- Mounting Type:Through Hole
- Package / Case:TO-218-3
- Supplier Device Package:SOT-93
